24S Battery Voltage Tester, 5" LCD Voltage Gauge, Precision Voltage Detector for NMC / LiFePO4 / LTO Batteries, Type-C Universal Socket, M6T24
Product details
| Management number | 246982616 | Release Date | 2026/08/16 | List Price | US$34.00 | Model Number | 246982616 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Introducing the M6T24 24-Channel Precision Voltage Monitor, a sophisticated testing device designed for comprehensive battery pack analysis. This versatile monitor supports multiple battery types including ternary lithium, LiFePO4, and lithium titanate batteries. With the capability to monitor 1-24 battery strings simultaneously, it offers exceptional precision with 1mV voltage detection resolution and 10mV measurement accuracy. The device features differential pressure monitoring with a 5V range and operates via 5V external power supply. Its compact design measures 122.5mm x 73mm x 16.5mm, with convenient mounting holes at 101.5mm and 50mm center distances. The integrated Type-C Universal Socket ensures modern connectivity options. The clear digital display shows critical parameters including total voltage, individual cell voltages, and differential values, making it an essential tool for battery maintenance and testing applications. Perfect for professionals requiring precise battery diagnostics and monitoring capabilities.
- 24-Channel Monitoring: Precision voltage monitor detects and analyzes 1-24 series battery pack parameters with real-time display of test values for comprehensive battery management
- Wide Battery Compatibility: Suitable for ternary lithium, LiFePO4 (lithium iron phosphate), and lithium titanate battery modules with differential pressure monitoring capabilities
- High Precision Measurement: Features 1mV voltage detection resolution and 10mV voltage measurement accuracy with maximum differential pressure range of 5V for reliable monitoring
- Convenient Connectivity: Equipped with Type-C universal cell phone socket for easy connection and powered by 5V external power supply method
- Compact Dimensions: Measures 122.5mm x 73mm x 16.5mm without case, with center hole distances of 101.5mm and 50mm for flexible installation options
| ASIN | B0GHZMYL6Z |
|---|---|
| Color | Green |
| Model | M6T24 |
| Brand Name | SUNKKO |
| Style Name | Professional |
| Unit Count | 1 Count |
| Item Weight | 1.5 pounds |
| Part Number | M6T24 |
| Manufacturer | SUNKKO |
| Power Source | Ac Power Supply |
| Item Dimensions | 4.81 x 2.87 x 0.65 inches |
| Number of Items | 1 |
| Measurement Type | Voltage |
| Compatible Devices | Batteries (NMC, LiFePO4, LTO) |
| Included Components | Power Cord, Data Cable, 2.0/2.54 Adapter, Adapter Board, Instruction |
| Upper Temperature Rating | 85 °C |
| Maximum Operating Voltage | 5 volts |
| Minimum Operating Voltage | 5 volts |
